FDA-Bond 8 Medical Grade Epoxy Adhesive, Two Part Easy Mix Application

$4.99
Shipping:
Calculated at checkout
Quantity:

Product Description

FOOD AND DRUG APPLICATIOON EPOXY ADHESIVE


PRODUCT DESCRIPTION:

FDA-Bond 8 Medical Grade Epoxy Adhesive, Two Part Easy Mix Application EPOXY ADHESIVE is a low viscosity epoxy resin system specifically developed for bonding and coating applications in accordance with Title 21, U.S. Code of Federal Regulations, Food and Drug Administration (FDA) Chapter 1, Sub Part B, Sections 175.105 and 175.300.

PRODUCT PROPERTIES:

Appearance Amber
Cure Type Heat cure or Room Temperature
Benefits Low viscosity
easily mixed
effective electrical insulator
low permeability to gasses and vapors
Mix Ratio by weight 100:100 / Resin: Hardener
Typical Applications FDA Grade Applications, food packaging, indirect contact with food and medical applications

UNCURED PROPERTIES:

Viscosity @ 25 C, cps 1,500 (After Mixing)
@ temperature 77.0 F, 25.0 C
Thixotropic Index 1.0
Specific Gravity, mixed 1.11
Reactive solids contents, % 100
Pot Life 45 minutes

CURE SCHEDULE:

4 Hours @ 65C
24 Hours @ 25C

CURED PROPERTIES:

Hardness, Shore D 65
Dielectric strength volts/mil 410

ELECTRICAL PROPERTIES:

Volume Resistivity 1.00e+14 ohm-cm
Dielectric Constant 3.35 @ frequency 1000 Hz

THERMAL PROPERTIES:

Operating Temperature -70 to 145 C
CTE, linear 29.4 in/in-F @ temperature 68.0 F

GENERAL INFORMATION:

For safe handling information on this product, consult the Material Safety Data Sheet, (MSDS).

HOW TO USE:

1) Carefully clean and dry all surfaces to be bonded.

2) Apply FDA-Bond 8 Medical Grade Epoxy Adhesive, Two Part Easy Mix Application completely mixed adhesive to the prepared surfaces, and gently press these surfaces together. Contact pressure is adequate for strong, reliable bonds; however, maintain contact until adhesive is completely cured.

3) Some separation of components is common during shipping and storage. For this reason, it is recommended that the contents of the shipping container be thoroughly mixed prior to use.

4) Some ingredients in this formulation provided may crystallize when subjected to low temperature storage. A gentle warming cycle of 52C for 30 minutes prior to mixing components may be necessary. Crystallized epoxy components do not react as well as liquid components and should be re-dissolved prior to use for best results.

AVAILABILITY:

This epoxy can be supplied in various different packages.
